Product Overview
T-6125NS is a nano-filled, low refractive index optical UV resin based on polyurethane acrylate chemistry. It is designed for advanced optical coating applications where precise refractive index control, thin-film uniformity, and high optical clarity are essential.
Cured by acrylate free-radical polymerization, T-6125NS delivers an ultra-low refractive index of 1.25. It combines rapid curing, good surface drying, excellent re-adhesion and recoatability, and strong compatibility with acrylate UV resins and monomers.
Whether you are developing AR/VR display films, multi-layer optical laminates, or submicron and nanoscale coatings, T-6125NS provides a reliable material platform for high-performance optical designs.
Key Features
Ultra-low refractive index: RI 1.25
Nano-filled polyurethane acrylate UV resin
Acrylate free-radical UV curing system
Fast curing with good surface drying
Excellent re-adhesion and recoatability
High compatibility with acrylate UV resins and monomers
Low haze and high light transmittance
Suitable for submicron and nanoscale coatings
Fluorine-free formulation
Supports multi-layer film bonding and lamination
Broad process adaptability
Typical Properties
| Property | Value |
|---|---|
| Tg | 70°C |
| MW (GPC) | 650 |
| Elongation at Break | 20% |
| Acid Value | max. 1 mg KOH/g |
| Refractive Index | 1.25 |
| Viscosity at 25°C | 100–300 mPa·s |
| Specific Gravity | 1.05 |
| Effective Content | 50–55% |
Typical values are for reference only and should not be used as specification limits.
Applications
AR/VR Display Films
T-6125NS is particularly suitable for AR/VR display film applications. Its low refractive index and nano-filled formulation help enable precise optical design while maintaining extremely low haze and high light transmittance.
Submicron and Nanoscale Optical Coatings
The resin is compatible with low film thickness requirements, including submicron and nanoscale coatings. This makes it suitable for advanced optical layers where thickness control and optical clarity are critical.
Multi-Layer Film Lamination
T-6125NS offers good re-adhesion and recoatability, allowing it to be used in multi-layer film composites and lamination processes. It is fluorine-free and can bond multiple film layers with wide process adaptability.
UV Optical Coatings
As a UV-curable polyurethane acrylate resin, T-6125NS can be used in various optical coating systems where low refractive index, fast cure, and compatibility with acrylate chemistry are required.
Compatibility and Processing Notes
Monomer Compatibility
T-6125NS is miscible with various acrylate UV monomers. To maintain the desired low refractive index, it is recommended to minimize the amount of monomer used.
Solvent Compatibility
T-6125NS is miscible with ester, ketone, and aromatic solvents. It is not soluble in a single alcohol solvent, but it can dissolve in mixed solvents containing alcohols and ethers.
Curing Mechanism
T-6125NS uses acrylate free-radical UV curing. It cures rapidly and shows good surface drying.
Packaging
Available in:
100 g
5 kg
20 kg plastic drums
More detailed application reference materials and MSDS are available upon request.
Why Choose T-6125NS?
T-6125NS is developed for formulators and optical engineers who need a low refractive index UV resin that does not compromise on processability. Its combination of ultra-low RI, nano-filler technology, fast UV cure, recoatability, and compatibility with acrylate systems makes it a strong candidate for next-generation optical coatings.
Key benefits include:
Ultra-low refractive index of 1.25
Excellent optical clarity with low haze
High light transmittance
Fluorine-free formulation
Good re-adhesion and recoatability
Compatible with multi-layer film bonding
Suitable for AR/VR display films
Adaptable to submicron and nanoscale coating processes
Contact Us
For samples, technical data sheets, MSDS, or application support for T-6125NS, please contact our team. We can help you evaluate whether this low refractive index polyurethane acrylate UV resin is suitable for your optical coating project.
T-6125NS - Low Refractive Index UV Resin for Advanced Optical Coatings.
